180mm turbo segment diamond cup wheel
Production Process：silver brazed.
Specifications：segment No. is 12,segment thickness is 5.5mm.
Equipment：angle grinder.
Package：blue box.
Product Description
This type of cup wheel silver brazed, with turbo type segment.
The diameter is 180mm, the segment number is 12. The optional diameter range of turbo grinding wheels is 105mm,115mm.125mm,150mm,180mm.
It can be widely used on rough surface grinding different kinds of concrete and masonry materials with superior efficiency.
The cup wheel can be installed on the angle grinder and grinding machine.
We can supply OEM service. Special arrangement holes are for better cooling.
Product Parameters
| Item No. | Diameter | Segments No. | Segment Thickness | Arbor |
| CGWTC10505 | 105mm | 7 | 5.5mm | 7/8",5/8"-11,M14 |
| CGWTC11505 | 115mm | 8 | 5.5mm | 7/8",5/8"-11,M14 |
| CGWTC12505 | 125mm | 9 | 5.5mm | 7/8",5/8"-11,M14 |
| CGWTC15005 | 150mm | 11 | 5.5mm | 7/8",5/8"-11,M14 |
| CGWTC18005 | 180mm | 12 | 5.5mm | 7/8",5/8"-11,M14 |
Features
1) Turbo Concrete Abrasive Cup Wheel has high strength, excellent wear resistance, and a low friction coefficient.
2) Its grinding efficiency and low grinding force generate less heat in the grinding process. This can decrease or avoid burns and cracks on the surface of the workpiece, and decrease the equipment's wear and energy consumption.
3) The high wear resistance can lead to good grinding quality and high grinding precision.
4) Metal bond diamonds long lifespan and long dressing period can greatly increase the work efficiency, and improve the worker's' labor environment while decreasing the product's labor intensity.
Application
The turbo diamond wheel can be widely used on rough surface grinding different kinds of concrete and masonry materials with superior efficiency.
Company Profile
Corediam Tools Co., Ltd, as a high-tech enterprise, concentrates on researching & developing, manufacturing and marketing diamond tools industry.We have the most extensive, innovative and powerful range of diamond tools for Construction, Stone and DIY markets. Corediam strives to be the leading professional supplier in the world by technology innovation.
Exhibition
The Cordiam team participated in many exhibitions (134th Canton Fair, Dubai Industry Exhibition, Las Vegas Exhibition), meeting old customers at the exhibition site, and also met many new customers.
